Specification
I. Case and Structure
1) SIZE: 100 (width) x 110 (height) x 3,090 (length) mm
2) Material: Aluminum
3) Color: White powder coating
4) Bracket: Movable rail type
5) Special Feature:
* Dustproof rubber - Prevents defects due to vibration during operation.
* Ball Bearing - Prevents the efficiency decrease due to friction during operation of the motor.
* Aluminum drums - Minimize weight and increase motor efficiency.
II. Motor Specification
1) Model: MERCURE 403S6 (SOMPY; France)
2) Nominal Speed: 30 rpm
3) Rated Power: 80w
4) Thermal Tripping: 140 ℃
5) Brake Type: Sliding
6) Shaft Drum: Aluminum ∅48.6
III. Screen Fabric
1) Material size: 3,000 (W) x 2,400 (H) mm
2) Material: Ultra Matte (Domestic)
3) Reflection rate: 0 ° / 1.0 Gain
4) Thickness: 0.7mm
5) Weight: 0.9Kg / ㎡
6) Teduru: 50mm Black Painting
7) Lower bar: Black Aluminum Bar
8) Flame Retardation: The flame retardant performance test shall be performed by the relevant authorities.
IV. Switch
1) Product Name: Locus location (UP / STOP / DOWN)
2) Model: WOE-6310 (Woojin Electric; Electrical Appliance Safety Certification)
3) Certification number: SA02004-2005A (Industrial Technology Testing Center)
V. Production
1) The roll screen is raised and lowered by the upper rotation method.
Roll the upper roll shafts 2½ times to make sure there is no crease.
2) The connecting part of SCREEN fabric is treated at high frequency and bonding,
do not change the image.
