Specification
AC Voltage meter Line input / output (use of the voltage)
Channel 8 ch
Ch load 220V/10A, 2200W
Total max load 220V/45A, 9900W
Output connector Standard three wire AC connector
Channel interval 2 sec
Link Enable
Link cable 4P DIN CABLE
Control Channel on / off switch, Lamp switch, Bypass switch
Lamp voltage / current DC12V / 400mA
FAN voltage / current DC24V / 1.5A
Power Consumption 55 watts
Main voltage 220V / 50Hz-60Hz, standard 3-wire, GND wire
Dimension (WxHxD) 480 x 89 x 305.5 mm
Weight 10 kg
Option ESP 201 스마트 컨트롤러 제어용 연결모듈
