RF to IR Extender & Power Detector - PSE100AD

PSE100AD is a model which combines the RF-IR extender with the power detector. It receives the control cords of IR at 2.4GHz wirelessly and controls instruments connected with wire. The power detector connected with PSE100A detects the ON and OFF of instruments to be controlled. Through setting up the integrated controller, it can transmit signals to 3 IR ports and control 3 power detectors.

Features of PSE100AD

Control Port : 3 IR Ports, 3 Power Detectors

Port type : Plug-in Terminal Block

CH & ID : Addressable 16 CH, 256 ID

Frequency :2.4GHz

Coverage : About 100meters

Power : 12V/1.5A SMPS DC Adapter

Dimension (mm) : 152.3x93.2x28 (WxDxH)

Weight(g) : 190

Case Color : White / Black
